15 Series Lockout L-O-X® Valves 1523B4004
- Easily identifiable with a yellow body and a red handle to control ON/OFF positions (non-Stainless Steel)
- Full size exhaust ports (equal to or larger than supply) provide rapid exhaust of downstream air and are threaded for silencers or remote exhaust lines
- Design only allows the valve to be lockable in the OFF (closed) position
- Fluorocarbon slipper seals for easy shifting, even after long periods of inactivity
- Includes integrated sensing port for pressure verification with either a visual pop-up indicator or electrical pressure switch
Need Help? No Problem!
Customer Service
Technical Service
+1 (416) 251-7677
Need Help? No Problem!
Customer Service
Technical Service
+1 (416) 251-7677
Product Information
Series | 15 Series Stainless Steel |
Actuation | Manual |
Function | 3/2 |
Soft Start | Not Included |
Thread Type | NPT |
Ambient Temperature (Celcius) | -1 to 80 |
Media Temperature (Celsius) | -1 to 80 |
Fluid Media | Filtered Air |
Construction | Spool |
Mounting | In-line |
Valve Body Material | 316 Stainless Steel |
Poppet/Spool Material | Stainless Steel |
Seal Material | Fluorocarbon |
Safety Category | Category 1 |
DGUV Certification | No |
CE Certification | No |
EAC Declaration | Yes |
CSA/UL Certification | No |
Exhaust Size | 1/2" |
PL Rating | PL c |
Inlet Size | 1/2 |
Outlet Size | 1/2 |
Body Size | 1/2 |
Operating Pressure | 0 to 300 psig (0 to 20.7 bar) |
Ports 2-3 Flow | 6.2 Cv (6100 Nl/min) |
Length | 4.3 in (108.5 mm) |
Width | 2.36 in (59.8 mm) |
Height | 10.47 in (265.8 mm) |
Ports 1-2 Flow | 5.8 Cv (5700 Nl/min) |
