Flow Controls 1968E4007
- Low profile, high capacity & right angle series available
- Available with NPT & BSPP port threads
- Low profile series includes slot & knob adjustment options
- High capacity series includes inline & offset orientation options
- Right angle series includes slot & knob adjustment options
Need Help? No Problem!
Customer Service
Technical Service
+1 (416) 251-7677
Need Help? No Problem!
Customer Service
Technical Service
+1 (416) 251-7677
Product Information
| Valve Type | Flow Control Valve |
| Series | 19 |
| Actuation | Pneumatic |
| Function | 2/2 |
| Thread Type | NPT |
| Construction | Poppet |
| Mounting | Inline |
| Fluid Media | Filtered Air |
| Operating Pressure | 5 to 150 psig (0.3 to 10 bar) |
| Valve Body Material | Cast Aluminum |
| Application | High Capacity |
| Size | 3/4" |
| Ambient Temperature | -40 to 175 F (-40 to 80 C) |
| Media Temperature | -40 to 175 F (-40 to 80 C) |
| Weight | 0.8 lb (0.4 kg) |
| Adjustment | Knob |
| Profile | Low |
| Inlet Pipe Size | 1/2" |
| Outlet Pipe Size | 1/2" |
| Avg Cv | 7.5 |
| Length | 3.75 in (70 mm) |
| Width | 1.56 in (40 mm) |
| Height | 3.06 in (78 mm) |
+
Flow Controls
1968E4007
Contact Us for a 3D Model
+
Flow Controls
1968E4007
Contact ROSS Canada for Ordering Information
+
